C系列单向阀 管式单向阀

C系列管式安装单向阀提供了允许液流从一方向上流过，而反向截止的功能。按制作材料的不同，该型阀可适宜在液压或气动系统中使用。该型阀采用独特的锥阀芯和阀芯导向结构，即使在大流量和存在脉动的工况下，也能确保功能可靠。相对于球阀芯，这种锥阀芯更有利于减小磨损和振动，其阀芯及弹簧的导向结构能***工作的稳定性。

技术参数:

规格、工作压力、压降及额定流量：

200 工作压力 钢材质350bar 黄铜材质140bar 压降10bar 额定流量40l/min;

400 工作压力 钢材质350bar 黄铜材质140bar 压降10bar 额定流量65l/min;

600 工作压力 钢材质350bar 黄铜材质140bar 压降10bar 额定流量110l/min;

800 工作压力 钢材质350bar 黄铜材质140bar 压降10bar 额定流量155l/min;

1200 工作压力 钢材质350bar 黄铜材质140bar 压降1bar 额定流量112l/min;

1600 工作压力 钢材质210bar 黄铜材质34bar 压降1bar 额定流量160l/min;

6C管式单向阀 6C系列单向阀的功能与C系列单向阀相同，但采用公制连接螺纹。其只允许液流从一个方向上流过而反向截止。

特点：

螺纹连接口形式符合***6149标准，带有O型圈锥形面密封槽口；公制连接螺纹；采用O型密封圈，能可靠地防止螺纹管接头与连接螺纹之间的泄漏；可在全世界范围内进行更换。

技术参数：

规格、公称压力、流量、连接螺纹：

规格616 公称压力350bar 流量65l/min 连接螺纹M16*1.5;

规格818 公称压力350bar 流量110l/min 连接螺纹M18*1.5;

规格1022 公称压力350bar 流量155l/min 连接螺纹M22*1.5;

规格1227 公称压力350bar 流量240l/min 连接螺纹M27*2;

开启压力：0.35bar;

材质：钢阀体；不锈钢锥阀；不锈钢导向座；不锈钢弹簧；

密封件：丁腈橡胶/氟橡胶；

型号列表：

6C1022S

6C1227S

6C1227S65

6C1633S

6C2042S

6C2042S65

6C2448S

6C616S

6C818S

6C616S

6C818S

6C1022S

6C1227S

C200B

C200B-M

C200B-V

C200B20

C200B65

C200S

C200S-V

C200S1

C200S65

C2000B

C2000S

C2000S1

C2000S20

C2000S30

C2000S65

C2000S80

C2020S

C2020S20

C2020S65

C2400S

C2400S1

C2400S20

C2400S30

C2400S45

C2400S65

C2400S80

C2420S

C2420S1

C2420S20

C2420S35

C2420S45

C2420S65

C3200S

C3200S1

C3200S20

C3200S65

C3220S

C3220S65

9C1200B

9C1200S

9C1200S20

9C1200S65

9C1600B

9C1600B1

9C1600S

9C1600S20

9C1600S65

9C200B

9C200S

9C200S65

9C2000S

9C2000S20

9C2000S65

9C2400S

9C2400S1

9C2400S30

9C2400S65

9C3200S

9C400B

9C400B65

9C400S

9C400S-V

9C400S20

9C400S65

9C600B

9C600B65

9C600S

9C600S-V

9C600S1

9C600S20

9C600S65

9C800B

9C800B1

9C800B10

9C800B65

9C800S

9C800S-V

9C800S1

9C800S20

9C800S65

9C800S65-VXB273

9C800S80

9C200B65 9C200B65

9C600S40 9C600S40

C400B

C400B-M

C400B-V

C400B1

C400B1-V

C400B10

C400B15

C400B20

C400B25

C400B65

C400B80

C400S

C400S-M

C400S-V

C400SS

C400SS1

C400SS15

C400S1

C400S20

C400S25

C400S65

C400S80

C420B

C600B

C600B-M

C600B-V

C600B1

C600B1-V

C600B10

C600B20

C600B20-M

C600B30

C600B40

C600B65

C600S

C600S-M

C600S-V

C600SS

C600SS20

C600S1

C600S10

C600S15

C600S20

C600S30

C600S40

C600S65

C600S80

C620S

C620S-M

C620S-V

C620S1

C620S20

C620S65

9C1200B65 9C1200B65

9C1200S80 9C1200S80

9C1600B65 9C1600B65

9C200B65 9C200B65

9C600S40 9C600S40

C800B

C800B-M

C800B-V

C800B1

C800B10

C800B20

C800B30

C800B50

C800B65

C800S

C800S-M

C800S-V

C800SS

C800SS1

C800S1

C800S10

C800S20

C800S30

C800S65

C800S80

C820S

C820S-M

C820S-V

C820SS

C820S1

C820S15

C820S20

C820S65

C820S80

9C800B

9C800B1

9C800B10

9C800B65

9C800S

9C800S-V

9C800S1

9C800S20

9C800S65

9C800S65-VXB273

9C800S80

C1020S

C1020S-V

C1020S20

C1020S65

C1200B

C1200B-V

C1200B1

C1200B10

C1200B20

C1200B65

C1200S

C1200S-V

C1200S1

C1200S10

C1200S20

C1200S25

C1200S35

C1200S50

C1200S65

C1200S80

C1220B

C1220S

C1220S-V

C1220S1

C1220S10

C1220S20

C1220S20-V

C1220S35

C1220S65

C1220S80

9C1200B

9C1200S

9C1200S20

9C1200S65

9C1600B

9C1600B1

9C1600S

9C1600S20

9C1600S65

9C200B

9C200S

9C200S65

9C2000S

9C2000S20

9C2000S65

9C2400S

9C2400S1

9C2400S30

9C2400S65

9C3200S

9C400B

9C400B65

9C400S

9C400S-V

9C400S20

9C400S65

9C600B

9C600B65

9C600S

9C600S-V

9C600S1

9C600S20

9C600S65

9C800B

9C800B1

9C800B10

9C800B65

9C800S

9C800S-V

9C800S1

9C800S20

9C800S65

9C800S65-VXB273

9C800S80

C1600B

C1600B1

C1600B15

C1600B20

C1600B65

C1600S

C1600S1

C1600S10

C1600S15

C1600S20

C1600S35

C1600S50

C1600S65

C1600S80

C1620S

C1620SH

C1620S1

C1620S20

C1620S65

9C1200B

9C1200S

9C1200S20

9C1200S65

9C1600B

9C1600B1

9C1600S

9C1600S20

9C1600S65

9C200B

9C200S

9C200S65

9C2000S

9C2000S20

9C2000S65

9C2400S

9C2400S1

9C2400S30

9C2400S65

9C3200S

9C400B

9C400B65

9C400S

9C400S-V

9C400S20

9C400S65

9C600B

9C600B65

9C600S

9C600S-V

9C600S1

9C600S20

9C600S65

9C800B

9C800B1

9C800B10

9C800B65

9C800S

9C800S-V

9C800S1

9C800S20

9C800S65

9C800S65-VXB273

9C800S80

9C1200B65 9C1200B65

9C1200S80 9C1200S80

9C1600B65 9C1600B65

9C200B65 9C200B65

9C600S40 9C600S40

淄博鼎科贸易有限公司单向阀的现货型号： C800B C1200S CS800S CS1200S CS1600S R32S07S4SN CS1600S N200B 9F200S 9C1200S 节流阀 FM6DDKV FM2BBKV FM2DDDKV FM2DDKV 9MV400S 叠加阀 CPOM2BBV CPOM2BB50V CPOM4DDHTV25 RM2AT17SV RM2BT17SV RDM2BT17SV RDM2PT35KVG RDM2ATBT35SV10 RDM2ATBT35SV10 PRDM2PP21KVG

淄博鼎科，金诚合作，0533-3070546 13235338520

其他常规型号：

C800B C800B-M C800B-V C800B1 C800B10 C800B20 C800B30 C800B50 C800B65 C800S C800S-M C800S-V C800SS C800SS1 C800S1 C800S10 C800S20 C800S30 C800S65 C800S80 C820S C820S-M C820S-V C820SS C820S1 C820S15 C820S20 C820S65 C820S80 C400B C400B-M C400B-V C400B1 C400B1-V C400B10 C400B15 C400B20 C400B25 C400B65 C400B80 C400S C400S-M C400S-V C400SS C400SS1 C400SS15 C400S1 C400S20 C400S25 C400S65 C400S80 C420B C600B C600B-M C600B-V C600B1 C600B1-V C600B10 C600B20 C600B20-M C600B30 C600B40 C600B65 C600S C600S-M C600S-V C600SS C600SS20 C600S1 C600S10 C600S15 C600S20 C600S30 C600S40 C600S65 C600S80 C620S C620S-M C620S-V C620S1 C620S20 C620S65
